B. A. Caulkett Ltd is a long established UK based, family run business, with over 30 years’ experience in the design and manufacture of high quality re-handling attachments for loading shovels in a variety of industries and applications. B. A. Caulkett products are designed and manufactured to our customers’ requirements and their specific application using the latest CAD software.

Contact us
BA_Caulkett_logo_

The BAC brand is synonymous with performance and quality

BA Caulkett Lightweight High Tip Buckets

BAC Lightweight buckets are ideal when you need a lightweight, bucket suitable for free flowing materials up to 600kgm³

View Our Ultra Products
BAC ultra logo B. A. Caulkett

BAC Ultra buckets are lightweight, suitable for materials 800kgm³ and are built to last.

View Our Extreme Products
BA Caulkett Ultra Plus High Tip Bucket

BAC Ultra Plus buckets are designed to work with materials up to 800kgm³ & feature larger rams, improved greasing and hose protection

BAC extreme logo B. A. Caulkett

BAC Extreme products are designed for aggressive, abrasive operating conditions. Designed to be incredibly strong and robust.

View Our Extreme Products
BAC custom logo B. A. Caulkett

BAC Custom buckets are designed to meet your specific requirements and operating needs. From specific widths, built to your capacity requirements we can build a bucket to your exact specification.

What Makes Us Different

Over the last 10 years B. A. Caulkett Limited has gone from strength to strength. We have relocated to larger premises, invested in the latest CNC press brakes, guillotines and plasma cutters and we are currently in the process of building an additional purpose built factory, due for completion Winter 2018. This investment has allowed us to achieve a faster and larger production capability. The investment is due to feedback received by our customers who require a British manufactured and supported product, with readily available backup and technical support.

To see the complete range of Loading Shovel Attachments and High Tip Buckets click here

High Tip Bucket Bucket Styles

BA Caulkett Lightweight High Tip Buckets
BA Caulkett Ultra High Tip Bucket
BA Caulkett Ultra Plus High Tip Bucket
BA Caulkett Extreme High Tip Bucket
CharacteristicLightweightUltraUltra PlusExtreme
Suitable for freeflowing materials up to 600kg/m³xxxx
Materials up to 800kg/m³xxx
Material Usage
Suitable for all materialsx
Rams
Horizontal Rams: Positioned parallel to the bucket frame. This design prioritises faster tipping action and higher capacity for lightweight materials.xxx
Vertical Rams: Positioned perpendicular to the bucket frame. This orientation offers greater structural strength for handling heavy or dense materials.x
Horizontal ram50mm rod50mm rod60mm rod
Vertical ram65mm rod
Bucket construction
Available curved or straight sidesxxxx
Built in spill guardxxxx
Legs (single piece)35mm45mm45mm
Hooks (single piece)35mm45mm45mm60mm
Box section frame and solid legsxxx
Heavy duty double tube frame and box legx
Leg pins and bushes60mm Nylon60mm Nylon60mm Nylon70mm Brass
Bolt on edge20mm25mm25mm25mm to 40mm
Floor and tunnels6mm8mm8mm8mm to 10mm
Wear plates and internal / external plates8mm10mm10mm15mm
Front side cutter15mm25mm25mm25mm
Bolt on heel platesxxxx
Greasing system6 point on all pins6 point on all pins2 pointSingle point
Hydraulics
Cross line relief valvexxxx
All hoses excluding fittingsxxxx
Plastic hose sheathingxx

Identify The Best Bucket For Your Needs

wood chippings for use with a high tip bucket ba caulkettWood Chippings
gravel and aggregates for high tip bucket B. A. CaulkettAggregates
Grain
Waste & Recycling
